Scale Agusta A109

[D.O.G.]

Word of mouth does get around.



[James M. Lewis]

So right my friend



[fran11784]

I don't get why they make you check a box for shipping protection?? Never have I had to do that anywhere else ever! They lost the sale of a helicopter because they wanted 18 bucks more for shipping protection. I simply went somewhere else with none of that bull.



[Tony]

I don't get why they make you check a box for shipping protection?? Never have I had to do that anywhere else ever! They lost the sale of a helicopter because they wanted 18 bucks more for shipping protection. I simply went somewhere else with none of that bull.

I 100% agree. They are not an insurance company, so this is bordering on fraud.

But this build will continue. I may do a little work on it today since we are waiting on parts for the new aquarium (yea, you heard right lol). So things in the house are on hold, so may do a little more work to the Agusta.



[Tony]

So I just grabbed the fuselage from the shelf (minding very carefully where the ceiling fan is....) and it hit me, I need more parts.

Question for you all. The balls and link ends are SUPER tight. Way too tight to actually assemble like this. What do you think, replace the balls, links and ends? Just the ends? Or just buy a reamer to size them correctly?



[Tony]

Thank you eBay for doing what helidirect couldn't!



[Tony]

Welp, I pulled out the hardware to mount the servos, and this is all of it... Can you guess what is missing?



[D.O.G.]



[Tony]

Hm... I think Murphy has been talking to this helicopter in their free time. Turns out, the Align 730MX's bolt pattern is wider than the bolt holes on the motor plate... Not good. And I don't have a mill to make a new plate. hm... Anyone have any ideas?



[Tony]

Motor bolt pattern is 30mm on center spread, motor plate is 25mm. Unfortunately it's not as simple as drilling a hole as the motor does need to slide to adjust gear mesh



[Tony]

Wanted thread for a new motor has been created. Let me know if you have one:

Wanted: - Align 600 Motor w/ 25mm Screw Spacing

Well, it seems the Agusta has been talking to Murphy because so far if it can go wrong, it has lol. I purchased an Align 730mx motor not knowing the spacing on the helicopter motor mount, and wouldn't you guess it, the motor has a 30mm spacing and the motor plate has a 25mm spacing. If you have...

www.rc-help.com



[Tony]

Ball Reaming Tool has been ordered. Need one anyway for Murphy... Will likely just order new ends as well to be safe. I have measured all the balls, and they all measure out at 4.7mm, so right on size.



[fran11784]

Hey Tony, how wide is that plate? What about a different plate?



[Tony]

A different plate would work as long as it has the 30mm spacing. Plate side to side is 54mm



[Tony]

One issue resolved. Servo nuts have printed. Included the file below if you need them for 600 size.



[fran11784]

Here is what I have and don't think it will work without some machining, but a 600 pro plate may work. I know its 54mm just not sure of the motor bolt pattern. I have a motor but its 30mm spread also.

Align 600pro Motor Mount H60219a for sale online | eBay

Find many great new & used options and get the best deals for Align 600pro Motor Mount H60219a at the best online prices at eBay! Free shipping for many products!

www.ebay.com



[Tony]

The side hole spacing for the frame on mine is 45mm. Yours is also 5mm thicker so would need to be machined. And there is no slots, that's weird lol.

And that link for ebay.... is for HeliDirect... Just wanted to point that out hahaha.

I will look into the Pro mount and see if I can find specs on it.



[fran11784]

Helidirect?? opps. I've been looking for specs. Grand RC has the mount also. I have a scale huey with a Align 600 pro in it. I'll see if I could see anything from the top. Like I said, 99% sure it's a 54mm frame width. Let me see what I could find out too.



[Tony]

Worst case I can get a 1/8" end mill and use it to do some plunge cuts then do a very very light run to clean up the ridges. I just hate doing that on a drill press because it can drop the chuck with lateral loads like that. But, should be minimal loads. I just hate having that much of a hole in the plate on the inside. I guess I could get larger washers as well. One way or the other, I will get this bird in the air lol.



[fran11784]

I hear ya. They show this motor (HML75M03) to be used with that motor plate H60219A. So pretty sure it would work. The only other thing is the holes in the frame matching up to that plate. The motor plate holes in the frame are slotted? can't remember.

​
